Drive Solutions for PCB Manufacturing
Precision and Dynamics for Electronics Production
In PCB manufacturing, companies face the challenge of producing increasingly complex, smaller and more powerful structures at the highest quality level while remaining cost-efficient. Especially in the semiconductor industry, nanometre repeatability, vibration-free motion as well as flexible and scalable system solutions determine productivity and competitiveness.
By combining intelligent motion control, dynamic mechanics and vibration-free designs, JAT ensures your machines are always state of the art.
Typical applications in PCB manufacturing with the highest demands on drive technology:
- Laser structuring and cutting of rigid and flexible PCBs
- Photolithographic exposure with sub-micrometre accuracy
- Precise dispensing of solder paste or adhesives
- High-dynamic handling in assembly and singulation
- Drilling and milling of PCB layouts
- Inline inspection with camera systems and synchronised drive technology
- Contact-free processes in cleanroom applications (ISO 5)
- Roll-to-roll processes for flexible circuits
JAT Solutions for Your PCB Manufacturing
With long-standing industry experience and a comprehensive technology portfolio, JAT develops complete drive systems for PCB production, from concept to series maturity.
Proven solution examples:
1. Laserstrukturieranlage mit Luftlagerachsen
For ultra-precise laser processes on photonic PCBs. Contact-free drives prevent particle generation, CFRP axes minimise inertia, and air bearings ensure vibration-free operation. Control and sequence processes are handled by the ECOVARIO© 616D.
2. Modular gantry system for assembly lines
Scalable, compact and optimised for high speed. Linear motors with ECOVARIO® servo amplifiers and ECOSTUDIO® commissioning software ensure rapid setup and maximum precision.
3. Camera-synchronised XY cross-table platform
Ideal for AOI systems. Synchronous motion with accelerations up to 5 m/s² enables fast image capture and evaluation.
4. Air-bearing rotary axis
Low-profile positioning axis for PCB handling in the sub-micrometre range.
5. Roll-to-roll transport module
Precise web control in continuous motion. Sensor integration for tension, position detection and thermal monitoring. Axis and tilt table controlled by ECOVARIO® servo amplifiers and ECOMODUL.
6. Pick-and-place system for mini-LED assembly
Ultra-lightweight CFRP axes for maximum acceleration. Repeatability <2 µm, suitable for cleanroom use.
Whether for SMEs with specific project requirements or global semiconductor groups with high scaling needs, JAT delivers tailored solutions.
Request a custom solution now
Drive Technology for Maximum Process Stability
PCB production processes are highly sensitive to the smallest deviations in temperature, vibration and positioning. The requirements for drive solutions are accordingly complex.
Critical requirements for drives in PCB production:
- Nanometre-accurate positioning in exposure and inspection processes
- Maximum repeatability for consistent quality at high volumes
- High dynamics for shortest cycle times in pick-and-place or laser cutting
- Thermal stability through use of granite bases and air bearings
- Low-vibration operation for sensitive manufacturing steps
- Particle-free motion for ISO 5 cleanroom class
- Precise synchronisation for exact contour fidelity
- Scalability from pilot lines to fully automated production
- Easy integration into complex sensor, camera and process control systems
- Wear-free operation for long service life
With JAT you rely on a well-thought-out complete solution tailored to your application, from mechanics and software through to commissioning.
what our customer says: “With a CFRP cantilever and the weight reduction, we were able to increase throughput by almost 20%.”
Your Benefits with JAT in PCB Manufacturing
- Higher process reliability through precisely matched drive solutions and thermally stable assemblies
- Reduced scrap rates thanks to vibration-free, precise motion systems
- Shorter cycle times with high-dynamic axes and synchronised control
- Cleanroom-compatible solutions minimise particle emissions and enhance product quality
- Faster time-to-market through modular, ready-to-install systems from JAT’s complete portfolio
Why Choose JAT for PCB Manufacturing?
Industry expertise meets technology depth
JAT specialises in high-precision motion and positioning solutions for the semiconductor and electronics industries. Our interdisciplinary team understands your processes and requirements, from wafer to finished module.
Complete solutions from one source
We cover the full spectrum: mechanics, electronics, software, testing and production, all in-house. This guarantees perfect coordination, short development times and minimal interface losses.
Modular platforms for maximum flexibility
Our systems are scalable and modular. They can be quickly and efficiently adapted to new processes, materials or form factors, ideal for dynamic production environments.
Trust in Proven Quality
ISO 9001 & ISO 14001 certified
Quality and environmental responsibility guaranteed
Experience from over 5,000 projects in 45 countries
Globally present, locally available
Cleanroom manufacturing up to ISO Class 5
Ideal for semiconductor processes
100% in-house expertise
From concept to series production
Over 200,000 delivered servo components worldwide
Reliability through experience
Sustainability
Developed and manufactured in a CO₂-neutral facility
